Self-supporting Thermoplastic Body Aluminum Hook Suspension Clamp Set for Insulated Overhead Conductors 25-95 mm²
- Certification
- CE
- Model Number
- ES1500B
- Packaging Details
- 50pcs/ctn , 50x21x21cm , 15kgs
- Supply Ability
- 100000PCS/Month
- Material
- Thermoplastic Aluminum Alloy Hook
- IEC Standard
- NFC 33-040
Self-supporting Thermoplastic Body Aluminum Hook Suspension Clamp Set for Insulated Overhead Conductors 25-95 mm²
Application:
The ES1500A Suspension Set is used to hang LV-ABC cables on poles with the insulated neutral messenger.
Features:
- It can be paired with all hooks and brackets, which are not affected by UV, weather and climate.
- The anchoring bracket is made of corrosion resistant aluminium alloy.
- The clamp and movable link is made of weather resistant and mechanically reliable insulated polymer.
- Hang the self-supporting insulated wire on the bracket with maximum angle of 60 degrees.
- Standard:NFC 33-040,EN 50483-3
| Item No. | Cross section (mm2) | Conductor(mm) | Breaking load |
| ES1500B | 25-95 | 5-14 | 12KN |
